Product attributes
Sensor structure capable of withstanding impacts exceeding 50000g
Single integrated dual axis accelerometer based on MEMS and CMOS circuits
Digital analog mixed signal processing for monolithic design
Compliant with RoHS standards
Comes with on-chip sensitivity compensation to cope with temperature changes
Requirement based self testing function
± 5g dynamic range, sensitivity of 250mV/g
Resolution better than 1mg
Within the temperature range of 40-95 ℃, the temperature drift of 0g is less than ± 80mg
The bandwidth is 27Hz
Single power supply operation from 4.50~5.25V
Small size surface mount packaging, 5mm x 5mm x 2mm
Improved thermal gradient performance
