Product attributes
VDD power supply: 2.65-3.6V
IO power supply: 1.2V~3.6V
I2C address user configurable interface
I2C communication clock frequency can support up to 3.4MHz
I3C communication clock frequency can support up to 12.5MHz
Integrated silicon-based linear sensor
Support bias, sensitivity, and nonlinear compensation functions
Built in 16 bit ADC for analog-to-digital conversion of Hall sensor signals
Built in hardware PID control algorithm
Provide an H-bridge circuit with 1 channel, 11 bit accuracy, and maximum ± 170mA driving capability
6-pin, WL-CSP (0.63 × 2.37 × 0.315mm) ultra small package
